JN0-460 Exam Dumps and Practice Questions

According to Juniper Networks' documentation on campus fabric and EVPN-VXLAN architectures, a Virtual Routing and Forwarding (VRF) instance---conceptually referred to within the Junos OS as a routing instance---is typically used to provide macro-segmentation by logically separating a single physical network into multiple, isolated virtual networks.2 In the context of a modern campus fabric managed by Juniper Mist, VRFs allow network administrators to create distinct routing domains that maintain their own independent routing and forwarding tables.3

This separation is essential for multitenancy and security.4 For example, an organization might use one VRF for 'Corporate_IT' and another for 'Guest_WiFi' or 'IoT_Devices'. Because each VRF operates with its own routing table, traffic belonging to one instance is completely isolated from traffic in another by default; packets cannot travel between VRFs unless an administrator explicitly configures 'route leaking' or directs the traffic through a stateful firewall for security inspection. This architectural approach also permits the use of overlapping IP address spaces, as the routing decisions for one tenant do not interfere with the address entries of another.5

In a Juniper Mist-driven campus fabric (such as Core-Distribution or IP Clos), the Mist portal streamlines the creation of these VRF instances as part of the fabric workflow.6 Once a VRF is created, specific VLANs (and their corresponding IRB interfaces) are assigned to it, ensuring that Layer 3 gateways are placed in the correct logical domain. While the underlay network (Option D) is responsible for providing the physical reachability (loopback to loopback) between switches using a protocol like eBGP, the overlay network leverages VRFs to deliver the actual isolated user services.

Wired AssurancedefinesSLEs (Service Level Expectations)to provide measurable performance indicators for wired networks. These metrics identify root causes of network degradation by monitoring switch health, connection success, and throughput performance.

''Juniper Mist Wired Assurance delivers AI-driven insights across key wired SLEs including Successful Connects, Throughput, and Switch Health, giving visibility into user experience and switch performance.''

Option A (Capacity):Incorrect --- capacity is used in wireless SLEs, not wired.

Option B (Successful Connects):Correct--- tracks connection success rate and anomalies.

Option C (Switch Health):Correct--- monitors hardware, software, and PoE status.

Option D (Coverage):Incorrect --- pertains to wireless SLEs.

Option E (Throughput):Correct--- measures data transfer rate, latency, jitter, and loss.

Juniper Mist AI for Wired -- Service Level Expectations (SLEs) Overview

Juniper Mist Wired Assurance -- SLE Metrics Reference

Juniper Mist AI Cloud -- Wired Visibility and Troubleshooting Guide

Mistwebhooksprovide real-time integration with external systems by streamingalertsandSLE (client) metrics.

They allow automation tools to react immediately to network health or performance changes.

Mist AI for Wired -- Webhooks Integration and API Guide

Mist Cloud Automation and Telemetry Reference

Within Mist Insights,Client Eventsshow state transitions such asreassociationand IP-level issues likeDHCP Denied.

These help correlate connectivity issues across wired or wireless edge connections.

Mist AI Insights Dashboard Guide

Mist AI for Wired -- Client Event Monitoring

According to Juniper Mist documentation, the Throughput Service Level Expectation (SLE) is the primary metric used to measure the ability of wired clients to pass traffic across the physical network without impedance. This SLE is critical for diagnosing issues with real-time, high-bandwidth applications such as video streams, which are highly sensitive to packet loss and latency. Within the Throughput SLE, the Storm Control classifier is specifically designed to identify 'bad user minutes' caused by the suppression of Broadcast, Unknown Unicast, and Multicast (BUM) traffic.

Storm control is a mechanism that enables the switch to monitor traffic levels and drop BUM packets when a specified traffic level---known as the storm control level---is exceeded. This prevents a 'traffic storm' from proliferating and degrading the overall performance of the LAN. While this is a vital security feature to prevent network meltdowns, it can inadvertently impact legitimate traffic. For instance, if multicast-based video streams or other heavy BUM traffic exceed the configured bandwidth percentage on a port, the switch will drop those packets to protect the rest of the network.

When troubleshooting video stream issues, network administrators should inspect the Storm Control classifier to see if it is triggering 'bad user minutes'. If the Mist dashboard indicates failures under this classifier, it signifies that the switch hardware is actively dropping packets because the BUM traffic limit has been reached. This provides immediate root-cause evidence, allowing the administrator to determine if they need to adjust the storm control thresholds within the Port Profile or investigate the source of the excessive broadcast traffic. By correlating these hardware-level events with the end-user experience, Mist AI simplifies the resolution of complex performance problems that traditional 'up/down' monitoring would miss.
