Free HP HPE7-A08 Exam Dumps and Practice Questions

10 original HPE Network Switching Professional Exam practice questions with answers and explanations.

Covers 2. Install And Configure The Wired Network Solution., 4. Troubleshoot The Wired Network Solution., 1. Create The Implementation Plan For The Wired Network Solution. and 3. Manage, Maintain, Optimize, And Monitor The Wired Network Solution..

Question types: single answer, multiple answers, order list and dropdown. A new question is added every 15 days.

10 questions

HP HPE7-A08 Practice Questions

Question 1

Topic: 1. Create The Implementation Plan For The Wired Network Solution.

Single Answer

A regional hospital is refreshing access switching in a building with 48-port closets. Each closet needs PoE for phones and access points, 10-GbE uplinks, and the ability to add a second switch later without redesigning the management plane. The hospital has a small operations team and will manage switches through HPE Aruba Networking Central. Existing racks have limited space, and the budget does not support modular chassis at the access layer. Which product family is the best fit for the access layer?

Correct answer: C

The CX 6300 family supports VSF, allowing supported switches to form a single logical switch with simplified management and expansion. PoE and high-speed uplink options are available, matching the access requirements without the cost and space demands of a chassis. The CX 6100 is a plausible low-cost choice, but it does not provide the required VSF expansion model. The CX 6400 is a modular chassis and conflicts with the closet space and budget constraints. The CX 4100i targets harsh or industrial environments rather than ordinary office closets.

Question 2

Topic: 1. Create The Implementation Plan For The Wired Network Solution.

Single Answer

A university is designing a new building with two equipment rooms and six wiring closets. The building requires routed links between rooms, resilient access uplinks, and centralized monitoring. The design team expects frequent VLAN changes during the first semester, but does not require a single chassis spanning the two equipment rooms. The budget allows supported switch stacking at access, while the university wants to avoid extending Layer 2 between the rooms. Which implementation approach best meets these requirements?

Correct answer: B

CX 6300 access switches support VSF, which meets the stacking requirement, while routed links between equipment rooms limit the Layer 2 failure domain. Central provides the requested centralized monitoring and configuration visibility. A single CX 6400 chassis does not span the rooms and extending its VLANs would violate the routed-boundary requirement. Standalone CX 6100 switches do not satisfy the supported access stacking requirement, and the proposed broad Layer 2 domain is explicitly undesirable. CX 4100i is intended for industrial environments and does not solve the design constraints better than the CX 6300.

Question 3

Topic: 2. Install And Configure The Wired Network Solution.

Multiple Answers

An enterprise has received new HPE Aruba Networking switches that will be managed in Central. The switches are staged on a temporary network that permits outbound access to Central, and the administrator has the serial numbers and MAC addresses. The company wants each switch to inherit its site-specific configuration from the correct group, and it wants to avoid making local changes that Central will later overwrite. The devices are not yet assigned in the Central inventory. Which two actions should the administrator take? (Choose two.)

Correct answer: C, D

Claiming or adding the devices places them in Central inventory, and assigning the intended group and site lets them receive the appropriate centrally managed configuration and organizational context. Making a full local configuration first risks conflicts with the configuration authority intended for the deployment. Blocking outbound access prevents the switches from communicating with Central during onboarding. A group can manage multiple devices, so creating an individual group for every switch is unnecessary and does not meet the stated configuration model.

Question 4

Topic: 2. Install And Configure The Wired Network Solution.

Dropdown

A contractor is installing an HPE Aruba Networking CX access switch from the CLI. The approved plan specifies VLAN 120 named VOICE and requires interface 1/1/12 to be an access port in that VLAN. The port must be administratively enabled after configuration. The switch is already at the appropriate configuration context, and no voice VLAN or trunk behavior is required. Complete the command sequence using the correct values for each blank.

Choose the correct value for each blank.

vlan \nname \ninterface 1/1/12\n no shutdown\n vlan access
Correct answer:

vlan 120\nname VOICE\ninterface 1/1/12\n no shutdown\n vlan access 120

The VLAN ID must be 120, its configured name is VOICE, and the interface access VLAN must use the same ID. On AOS-CX, creating the VLAN and applying `vlan access 120` to the interface establishes the requested access-port membership; `no shutdown` administratively enables the port. VLAN 12 and VLAN 1200 do not match the approved plan. The alternative names do not reproduce the specified VLAN name, and `voice-vlan` is not a substitute for the required access VLAN configuration.

Question 5

Topic: 2. Install And Configure The Wired Network Solution.

Single Answer

A financial services branch is moving employee ports to HPE Aruba Networking CX switches. Endpoints use 802.1X, but a small set of approved devices without a supplicant must be admitted through MAC authentication. Security requires that an unauthenticated device not receive normal employee access, and the branch must retain a local fallback if the authentication server is temporarily unreachable. Which configuration approach best addresses the requirements?

Correct answer: C

A port-access design using 802.1X with MAC authentication as an alternate method accommodates devices lacking a supplicant while retaining identity-based admission. A restricted role or VLAN prevents unauthenticated or fallback devices from receiving ordinary employee access. Using MAC authentication for every endpoint weakens the intended authentication posture and exposes the employee VLAN to MAC-based admission. Disabling access control removes the required security boundary. Permitting server-unreachable devices onto the employee VLAN violates the explicit restriction on unauthenticated access.

Question 6

Topic: 3. Manage, Maintain, Optimize, And Monitor The Wired Network Solution.

Order List

A company is formalizing configuration governance for a Central-managed switching fleet before a major change window. The team must preserve a known-good baseline, review the proposed change, deploy only after approval, and retain enough evidence to support rollback and audit. Production devices must not be used as the first place to discover configuration errors. Arrange the governance steps in the order they should be performed.

Drag the steps into the correct order, or use the arrows.

  1. Obtain change approval after reviewing validation results
  2. Deploy during the approved window and archive the resulting state
  3. Archive the approved baseline and record the change scope
  4. Validate the proposed configuration against a representative nonproduction target
Correct answer:
  1. Archive the approved baseline and record the change scope
  2. Validate the proposed configuration against a representative nonproduction target
  3. Obtain change approval after reviewing validation results
  4. Deploy during the approved window and archive the resulting state

Preserving the baseline first gives the team a known-good reference and supports rollback. Testing the proposed configuration on a representative nonproduction target can expose errors before production is affected. Approval should follow review of those validation results, rather than precede evidence-based assessment. Deployment then occurs within the authorized window, and archiving the resulting state records what was actually implemented for later audit and comparison.

Question 7

Topic: 3. Manage, Maintain, Optimize, And Monitor The Wired Network Solution.

Single Answer

A network operations center observes that several switch ports have increasing CRC errors and intermittent link resets. The affected ports connect to different endpoints, but all use the same model of patch cable installed during a recent cabling project. Switch CPU and memory are normal, and there are no corresponding spanning-tree topology changes. The service desk reports that moving one endpoint to a port in the same closet does not eliminate the errors. What is the best next action?

Correct answer: B

CRC errors indicate frames are arriving with physical-layer corruption, and link resets strengthen the case for checking cabling and link quality. Because multiple endpoints share recently installed patch cables and changing switch ports did not help, cable certification or replacement is the most direct next step. Changing spanning-tree cost addresses path selection, not corrupted frames. CPU is normal and cannot correct physical corruption. QoS affects traffic treatment after frames are received; it does not prevent CRC errors on the link.

Question 8

Topic: 4. Troubleshoot The Wired Network Solution.

Single Answer

A newly installed workstation cannot reach its default gateway. The switch reports the port as up, and the workstation's link speed is correct. The approved port plan assigns the workstation to VLAN 34, where the gateway address is 10.34.0.1/24. The workstation has a static address of 10.35.0.27/24 and its configured gateway is 10.35.0.1. A nearby workstation on VLAN 34 is operating normally. What is the most direct remediation?

Correct answer: D

The endpoint is configured for the 10.35.0.0/24 subnet, while its approved VLAN and gateway use 10.34.0.0/24. Correcting the workstation address and gateway to the approved VLAN 34 subnet resolves the IP mismatch without changing the network design. Moving the port to VLAN 35 would contradict the port plan and the working neighboring endpoint. Enabling routing does not correct a host's incompatible address and gateway. Replacing a switch is unwarranted because the port is up and another VLAN 34 endpoint works.

Question 9

Topic: 4. Troubleshoot The Wired Network Solution.

Order List

After a planned access-switch replacement, users in one department lose access to an application hosted on a routed network. The replacement switch is reachable through its management interface, but the department's access ports show no clients in the expected VLAN. The approved design and a known-good configuration archive are available. The change window is still open, and the team wants to isolate the cause before making a corrective production change. Arrange the troubleshooting actions in the order they should be performed.

Drag the steps into the correct order, or use the arrows.

  1. Apply the minimal verified correction and retest application reachability
  2. Confirm the affected ports' operational state and VLAN membership
  3. Compare the live port and VLAN configuration with the approved design
  4. Check endpoint addressing and gateway settings against the intended subnet
Correct answer:
  1. Confirm the affected ports' operational state and VLAN membership
  2. Compare the live port and VLAN configuration with the approved design
  3. Check endpoint addressing and gateway settings against the intended subnet
  4. Apply the minimal verified correction and retest application reachability

Begin with operational state and VLAN membership because the report specifically says clients are not appearing in the expected VLAN. Compare the live configuration with the approved design to identify a switch-side mismatch without guessing. If the switch configuration is correct, check endpoint addressing and gateway settings to distinguish a host-side problem. Only after identifying and verifying the discrepancy should the team apply the smallest corrective change and retest end-to-end reachability.

Question 10

Topic: 4. Troubleshoot The Wired Network Solution.

Multiple Answers

A distribution switch is forwarding voice and data traffic over a constrained uplink. During busy periods, users report choppy voice while bulk transfers remain fast. Interface counters show no physical errors or drops, and the uplink is consistently saturated. The voice packets carry the expected DSCP marking at the edge, but the distribution policy has not been reviewed since a recent migration. The organization cannot increase link capacity this quarter. Which two actions are the best next steps? (Choose two.)

Correct answer: B, C

With a saturated uplink and no physical errors, the distribution policy is a likely source of voice degradation. Verifying classification and preservation confirms that the expected DSCP marking reaches the switch's QoS pipeline. Checking egress queue treatment establishes whether voice receives appropriate service during congestion. Spanning-tree cost controls Layer 2 path selection, not queue priority. Disabling QoS removes differentiated treatment and can worsen voice quality. Saturation alone does not indicate defective optics, especially when counters show no physical-layer errors.
